Made To Measure Secondary Glazing

Made To Measure Secondary Glazing


Made to Measure Secondary Glazing - We manufacture & supply a wide range of products.



These made to measure secondary glazing products are based on the dimensions supplied.

The product range:


SmartSlider: Secondary Glazing with opening panels that slide from side to side (Horizontal Sliders).

These can be supplied glazed with 4mm or 6mm Acrylic, 4mm or 6mm Plate Polycarbonate or unglazed ready for 4mm or 6mm glazing.

All glazing materials are glass clear.

The frame is powder-coated aluminium in white.

The SmartSlider is available in 2 panels, 3 panels and 4 panels.

SmartHinge: These are hinged secondary glazing units and can be supplied hinged on either the left-hand or right-hand sides of the panel.

These can be supplied glazed with 4mm or 6mm Acrylic, 4mm or 6mm Plate Polycarbonate or unglazed ready for 4mm or 6mm glazing.

All glazing materials are glass clear.

The frame is powder-coated aluminium in white.

SmartFix: This is an aluminium frames single fixed panel that is secured in position using toggle clips. The panel can be removed for cleaning/maintenance of primary window.

These can be supplied glazed with 4mm or 6mm Acrylic, 4mm or 6mm Plate Polycarbonate or unglazed ready for 4mm or 6mm glazing.

All glazing materials are glass clear.

The frame is powder-coated aluminium in white.

SmartFrame: A fixed secondary glazing panel with uPVC frames, secured in position with screws hidden by the uPVC frame.

These can be supplied glazed with 2mm or 4mm Acrylic, 2mm or 4mm Plate Polycarbonate or unglazed ready for 4mm glazing.

All glazing materials are glass clear.


Benefits of Omega Secondary Glazing:


Secondary Glazing is installed in order to achieve one of two objectives:

Heat loss reduction.

Noise reduction.

Heat Loss reduction is best achieved by installing the secondary glazing as close as possible to the existing (window) glazing. The optimal dimension is 15 -20mm.

The glazing material would be 4mm thick.

This mainly implies that the secondary glazing frame is Face-Fixed to the existing window frame.

Noise reduction is best achieved by installing the secondary glazing between 150mm -200mm from the existing (window) glazing.

Use a different thickness glazing material from that employed in the existing window glazing. This often implies using 6mm thick glazing material as most common window glazing (both single-glazed and double-glazed) is 4mm thick.

The secondary glazing would be Reveal-Fixed into the window reveal.


SmartSlider
SmartSlider
SmartHinge
SmartHinge
SmartFix
SmartFix
SmartFrame
SmartFrame
